Jun 9 2010
Soenso Energy offers the Schuco Premium V flat plate solar collector. The copper solar collector utilized in the module is given an exclusive coating for increased energy absorption. The quality thermal insulation used in the module keeps the energy loss to the minimum. The frame used for encapsulating the solar plate is made of strong silver anodized aluminum for enhanced durability. The low iron glazing used in the module is highly transparent.
For increased protection the solar panel is covered by a half inch tempered glass and EPDM gasket. The design of the module offers increased flow control over conventional designs.
Schuco Premium V Flat Plate Solar Collector
The Schuco Premium V flat plate solar collector is manufactured utilizing erosion free materials for increased service life. The V flat plate solar collector measures 2152 mm x 1252 mm x 93 mm in size and offers a collecting surface area of 2.69 m². This solar panel weighs 55 kg. The Schuco Premium V flat plate solar collector offered by Soenso Energy incorporates a maximum number of four collectors in series. The volume of the heat transfer fluid utilized in the flat plate solar collector is 2 L and the minimum volume flow is 2.5 L/m. This flat plat solar collector uses Cu type of heat collecting pipes measuring 12.0 mm in diameter and offered in serpentine type of configuration.
The normal operating pressure of this module is 3.2 bar and its maximum operating pressure is 10 bar. The stagnation temperature of this flat plat collector is 194ºC, its maximum operating temperature is 120ºC and its thermal output is 2.0 kWth. This flat plate solar collector meets the CE certification requirements and EC guidelines.
Source: http://www.soenso.com
