New Hybrid MPPT Controller for Enhanced Photovoltaic Systems

In a recent study published in the journal Scientific Reports, researchers introduced a new direct current-to-direct current (DC-DC) converter with a hybrid maximum power point tracking (MPPT) controller tailored specifically for solar photovoltaic (PV) systems. Their technique could help achieve high voltage gain, low voltage stress, and good overall power quality.

solar panels, new developments

Image Credit: hrui/Shutterstock.com

Background

Solar energy is a promising renewable resource due to its abundance, cleanliness, and sustainability. One key challenge of solar PV systems is the nonlinear and variable output power. The amount of electricity solar panels produce depends on sunlight intensity, which can fluctuate throughout the day.

Solar panels typically produce a low-voltage output that needs to be boosted for efficient use in applications such as grid integration or electric vehicle battery charging (which often use voltages of around 400 V).

Other challenges include inherent limitations in efficiency, upfront costs, and the effects of partial shading, where parts of a solar panel receive less sunlight due to clouds or objects, reducing overall power output.

Power electronics converters and MPPT controllers are employed to overcome these challenges. Converters boost the voltage from the solar panels, while MPPT controllers ensure the system operates at the point of maximum power output (MPP). However, conventional solutions often have limitations, including low voltage gain, high voltage stress on components, and slow response times.

About the Research

The Scientific Reports study introduced an innovative DC-DC converter for solar PV systems. The system utilizes a single switch, two identical inductors, five capacitors, and four diodes. This configuration provides simplicity, a lower cost, and potentially higher efficiency than converters with more complex components. The converter can operate in continuous and discontinuous conduction modes, providing flexibility for different operating scenarios.

The system incorporates a hybrid MPPT controller, which combines an adaptive step genetic algorithm optimized (ASGAO) radial basis functional network (RBFN) with a perturb and observe (P&O) method.

The ASGAO-RBFN helps the system track the MPP under various operating conditions, including different sunlight intensities and temperatures. The P&O method then refines the operation to maintain efficient power extraction. This hybrid approach aims to achieve several benefits: fast convergence speed, high tracking accuracy, high efficiency, and robust performance under partial shading.

By quickly locating the MPP, the system minimizes energy losses during startup. The controller also ensures the system operates close to the MPP, even under fluctuating conditions, maximizing power output from the solar panels. Finally, the design is intended to maintain efficient operation even when parts of the solar panel are shaded.

The researchers conducted simulations and tests to assess the new converter's and controller's performance under various conditions, including input voltage, duty cycle, load resistance, and solar irradiation. These evaluations were conducted using MATLAB/Simulink and a programmable DC source. The paper compared the performance of the novel system with other existing systems, such as conventional boost converters, quadratic converters, and Z-source converters.

The proposed hybrid MPPT controller's performance was compared with various MPPT methods, including perturb and observe (P&O), P&O with artificial neural network (ANN), ANN with hill climb (HC), incremental conductance (IC), and genetic algorithm (GA) with P&O. Key parameters, such as the voltage conversion ratio, voltage stress, and current ripple of the proposed converter, were evaluated under different duty cycles and load conditions.

Research Findings

The outcomes showed that the proposed converter and controller improved significantly compared to existing systems. The converter exhibited a wider input voltage range, higher voltage gain (allowing for efficient use of the boosted voltage in applications like electric vehicle battery charging), lower voltage stress on components, lower power loss, higher efficiency, and lower current ripple. The MPPT controller demonstrated faster response and MPP tracking and effective MPP tracking under varying sunlight intensity and temperature conditions.

The proposed technique can be applied to solar PV systems for various applications, including electric vehicle battery charging, where the high voltage gain is beneficial, smart grid integration, and rural electrification. It can also be used for other renewable energy sources like wind, tidal, and fuel cell systems that require high voltage gain and a wide input voltage range. The MPPT controller's potential extends to other optimization problems requiring high gain and efficiency.

Conclusion

In summary, the novel system effectively improved the performance and efficiency of solar PV systems under various operating conditions. The converter's design offered simplicity and potentially lower cost, making it a promising advancement in solar energy technology.

Moving forward, the researchers acknowledged the limitations and challenges and suggested some directions for further improvement. They recommended optimizing the converter parameters, reducing the converter size and cost, and integrating the converter with other renewable energy sources. Moreover, they proposed using a fuzzy logic or neural network controller instead of the P&O method.

Find out more about solar panel equipment and technology here

Journal Reference

Kumar, S.S., Balakrishna, K. A new wide input voltage DC-DC converter for solar PV systems with hybrid MPPT controller. Sci Rep 14, 10639 (2024). https://doi.org/10.1038/s41598-024-61367-x, https://www.nature.com/articles/s41598-024-61367-x.
