Green ammonia production relies on precise control of hydrogen and nitrogen throughout the process. As renewable-powered hydrogen generation is known to fluctuate, consistent gas monitoring is critical to maintain synthesis efficiency, optimize purge rates, and ensure reactors are stable. On-line process mass spectrometry provides rapid, multi-component gas analysis to assist operators in monitoring key gases in real time and quickly respond to fluctuating process conditions.
Image Credit: Corona Borealis Studio/Shutterstock.com
What is Green Ammonia?
Ammonia is among the most important industrial chemicals in the world. The small molecule has a crucial role in fertilizer production, chemical manufacturing, energy storage, and upcoming decarbonization projects. As industries aim to lower their carbon emissions, the production of “green” and low-carbon ammonia is gaining more investment around the world.
Unlike traditional ammonia plants built for steady-state operation that depend on fossil fuels to produce hydrogen, facilities that handle green ammonia can vary in how hydrogen is produced because renewable energy availability fluctuates. Wind, solar, and other renewable sources may create dynamic operating conditions that introduce new process-control challenges in the ammonia synthesis loop.
Such evolving conditions heighten the need for rapid, consistent process gas analysis. On-line process mass spectrometry delivers fast, multi-component gas analysis over various process streams, ultimately assisting operators in monitoring important process parameters in real-time. With analysis times assessed in seconds as opposed to minutes, process mass spectrometry can deliver the analytical visibility needed for supporting flexible approaches to green ammonia production.
Producing Green Ammonia and Potential Issues
Producing green ammonia usually depends on hydrogen yielded from renewable-powered electrolysis, together with nitrogen from an air separation unit (ASU) or pressure swing adsorption (PSA) system. The hydrogen (H2) and nitrogen (N2) gases are subsequently compacted and put into an ammonia synthesis loop, where ammonia (NH3) is ultimately generated via the Haber-Bosch process.
The production of ammonia can be understood via the Haber-Bosch reaction:
While the synthesis of green ammonia has many similarities to that of traditional ammonia production, its hydrogen generation process can bring variability in flow rates, pressures, and gas compositions. The upstream nitrogen production process poses other problems, mostly stemming from the inevitable presence of trace contaminants.
Fluctuations in Hydrogen Production
Monitoring variability in the hydrogen feed is one of the main challenges in producing green ammonia. During production, hydrogen is usually created via water electrolysis, powered by renewable energy sources such as solar, wind, or hydroelectric power.
Variations in renewable energy production affect electrolyzer output, leading to fluctuations in downstream hydrogen availability. These fluctuations can then spread throughout the plant, ultimately affecting feed gas composition and the performance of recycle loops. If they reduce hydrogen supply, the synthesis loop can become nitrogen-rich, lowering conversion efficiency and affecting both reactor heat balance and cooling duty.
Nitrogen Contamination from Argon
Nitrogen is brought through an ASU or PSA system before the gases are compacted and diverted into the ammonia synthesis loop. Problems with nitrogen can emerge from the element’s resemblance to argon. Both are typically inert gases located in the Earth’s atmosphere, and they have boiling points within 10 °C of each other.
When nitrogen is isolated from air, a small quantity of argon will come with it. As bulk nitrogen is brought into the ammonia synthesis loop, a trace quantity of argon can also come with it. This argon will not react, however, as time passes, argon levels can accumulate inside the system.
A significant argon buildup dilutes the key reactants until the production reaction loses efficiency. Argon buildup can also increase compression and energy use because compressors must move more non-reactive gas through the recycle loop.
Consistent monitoring of process gases becomes increasingly crucial for sustaining efficiency, protecting catalyst performance, and supporting stable reactor control.
Rapid Analytical Feedback is Critical for Efficiency in Producing Green Ammonia
Maintaining the appropriate hydrogen-to-nitrogen ratio is essential for efficient ammonia synthesis and sustained catalyst performance. If hydrogen supply dips while nitrogen flow remains consistent, the loop can become nitrogen-rich. This can lower synthesis efficiency and affect reactor thermal management.
Monitoring argon accumulation is also critical to maximize purge rates and sustain efficiency during loop operation. Insufficient purging can lead to argon buildup, which dilutes the reacting gases and lowers conversion efficiency. Excessive purging can also remove valuable hydrogen from the system.
Without rapid analytical feedback, process control systems may react only after the process has shifted away from an ideal operating environment. Due to this, operators increasingly demand analytical systems with the following characteristics:
- Rapid response times
- Consistent on-line monitoring abilities
- Dependable multi-component analysis
- Stable long-term performance
- Elevated analytical precision
- Flexible multi-stream capability
- Possibility for integration with plant control systems
Online process mass spectrometry (process MS) gives the speed and process visibility required to support these needs.
Benefits of On-Line Process Mass Spectrometry over Other Analytical Approaches
While different analytical approaches can be utilized with the Haber-Bosch reaction, on-line process mass spectrometry provides benefits that other approaches do not. Process gas chromatography (GC) and process Raman spectroscopy are common alternatives for gas analysis when producing ammonia.
GC and process Raman spectroscopy both have benefits and weaknesses. For instance, gas chromatography can enable direct gas-phase analysis, and it is highly sensitive. But an average GC analysis takes two to five minutes per sample and can only run one analysis at a time. In the time it takes to track two or three points on a line, the ammonia production process could shift considerably away from ideal conditions.
Process Raman spectroscopy is a superb choice for multiple elements of rapid multi-stream gas analysis. It enables instant and in-line monitoring with high sensitivity. But it has one fundamental weakness with regard to the Haber-Bosch process: Argon is not visible with Raman spectroscopy. As the accumulation of argon is a key factor that affects how efficient the production of green ammonia can be, this is a significant drawback. Another point of contention is that Raman spectroscopy uses chemometrics, meaning it is adjusted for a specific pressure, temperature, and flow rate. Variation in these parameters will lead to a drift in the analyzer’s readings.
Unlike analytical methods that necessitate multiple dedicated analyzers for different process points, on-line process mass spectrometry can rapidly multiplex over different sampling points. This aids operators in tracking how gas composition evolves during the process. Such high-frequency data can support sophisticated approaches to process control by making possible earlier response to fluctuations in the availability of hydrogen, the composition of synthesis gas, recycle composition, and purge gas needs.
Just one process mass spectrometer can track multiple streams via a multi-stream sampler (RMS). The RMS supports selection from multiple sample streams – sometimes as many as 127 – while maintaining rapid switching times and dependable operation.
This enables one analyzer to track different process locations during the ammonia production process. Rather than solely depending on slower measurements or inferred values, operators can make use of direct gas composition data to optimize conversion efficiency, sustain reactor stability, and oversee thermal stress.
