Direct air capture (DAC) removes carbon dioxide (CO₂) directly from the atmosphere, but its high energy requirements remain a major challenge. Several studies published in 2026 explore ways to reduce this energy demand by developing alternative approaches to CO₂ capture and release. Two investigate electricity-driven regeneration methods, while a third examines how DAC could be integrated with methanol production in water-scarce regions.

Image Credit: wutzkohphoto/Shutterstock.com/Shutterstock.com

The Thermodynamic Problem

Air contains only around 400 parts per million of CO₂, so extracting it means concentrating a very dilute gas, which requires work. A standard calculation puts the ideal minimum at roughly 20 kJ per mole of CO₂, or about 0.44 GJ per ton. Real systems need far more, because they must move large volumes of air and release the CO₂ from whatever captured it.¹ Conventional temperature swing adsorption is reported to need 7.2 to 9.5 GJ of heat per ton of CO₂,² many times the ideal work.

Want to save this article for later? Click here.

What an Amine Sorbent Does

Amine groups are basic and bind CO₂ chemically, so a solid sorbent can capture the gas even at 400 ppm.³ In the conventional mechanism, one amine attacks a CO₂ molecule to form a zwitterion, and a second amine accepts the proton. Two amines are therefore needed per CO₂, which halves the theoretical capacity.² Regeneration reverses the reaction, usually with steam or hot water.² In humid air, co-adsorbed water raises the heat needed for desorption.⁴

How Electrochemical Approaches Change Regeneration

The first route keeps the amine but changes how it handles protons and delivers heat. Shen and colleagues built an amine-functionalized graphene aerogel in which point defects in the carbon act as proton traps, removing the need for a second amine.² They report about 1.1 amines per CO₂ under pure CO₂. From 400 ppm CO₂ in air at 80% relative humidity and 25 °C, with a gas velocity of 1 m per second, uptake was 6.57 mmol per gram, 28.8% above the previous record cited by the authors.²

Because the aerogel conducts electricity, it is regenerated by passing a current through it (Joule heating) instead of by steam. At 0.6 A, the bed reached the 80 °C desorption temperature, and the regeneration heat duty was 3.4 GJ per ton of CO₂ for 95% release, against the conventional range above.²

The second route moves the chemistry into solution, capturing CO₂ in an alkaline solution and regenerating it with electricity. Until now, high efficiency required a dilute hydroxide stream at about pH 13, which current air contactors cannot use, and concentrating it lowered current efficiency because protons and hydroxide recombine.⁵ Liu and colleagues separated CO₂ release from sorbent regeneration, using a tuned redox mediator and a synthesized cation exchange membrane. At 50 mA cm⁻², they report a capture-rate-normalized energy intensity of 0.22 GJ m² yr t⁻², three times better than previous work.⁵ A commentary notes that electrochemical DAC is a credible alternative to thermal methods only if highly alkaline solutions can be made efficiently.⁶ The two energy figures use different metrics and cannot be compared directly.

Coupling Capture to Conversion

Wenzel and colleagues modeled solid sorbent DAC feeding solid oxide electrolysis and methanol synthesis, powered by solar and wind, across more than 20,000 regions. The DAC unit supplies both CO₂ and water, and in 97% of regions the water from ambient air was sufficient. System efficiency ranged from 39% to 49% depending on weather, mainly because DAC energy demand varies with humidity and temperature. Meeting a projected 2050 demand of 500 million tons of methanol a year would cost an average of €604 per ton in the model.⁴ This couples separate units rather than combining capture and conversion in one device.

What Remains Unresolved

Durability. The proton-trap sorbent lost 3.7% of its uptake over the first 100 cycles, then held steady to 500 cycles,² and the redox-decoupled system was reported over 200 hours.⁵ Both are short compared with the years a plant must run.

Air-contacting. The aerogel's porosity exceeds 98%, which lowers capacity per unit volume to 52.6 mol per cubic meter, and the authors list contactor design as future work.² The redox-decoupled design aims to supply solutions concentrated enough for contactors, but performance in a large contactor is a separate question.⁵

Impurities. The proton-trap cycling data were collected under controlled humidity and gas velocity, and the main text does not describe exposure to dust or trace gases.² In the methanol study, higher DAC maintenance costs meant to reflect dust exposure raised methanol costs by about 1 to 2%.⁴

Scale. The proton-trap cost projection is for a 4,000 ton-per-year plant and gives a variable capture cost of $48 to $62 per tonne, up to 78% below temperature swing systems.² These are model outputs. The methanol study also assumes DAC energy demand falls to about 65% of present values.⁴

Electricity source. Every route relies on low-carbon power, and an early analysis noted that air capture must run on CO₂-neutral electricity to remove CO₂ on net.¹ The methanol study found cost and efficiency shifting with local wind and solar resources.⁴

These studies do not remove the energy penalty, but they show where it can be cut: proton management, regeneration electrochemistry, and the use of captured CO₂. Each result is still a laboratory or modeling result, and the unresolved points above will determine what reaches a plant.

References and Further Reading

1. House, K. Z., Baclig, A. C., Ranjan, M., van Nierop, E. A., Wilcox, J. & Herzog, H. J. Economic and energetic analysis of capturing CO₂ from ambient air. Proc. Natl. Acad. Sci. USA 108, 20428 to 20433 (2011). https://doi.org/10.1073/pnas.1012253108

2. Shen, Y., Pang, K., Zhao, W., Chen, L., Zhao, J., Ye, J., Zhang, B., Li, S., Li, W., Xu, Z., Meng, J., Gao, X. & Zhang, S. Proton trap engineered electric swing adsorption for scalable and cost-effective direct air capture. Nat. Commun. 17, 8885 (2026). https://doi.org/10.1038/s41467-026-75916-7

3. Sanz-Pérez, E. S., Murdock, C. R., Didas, S. A. & Jones, C. W. Direct capture of CO₂ from ambient air. Chem. Rev. 116, 11840 to 11876 (2016). https://doi.org/10.1021/acs.chemrev.6b00173

4. Wenzel, H., Schöb, T., Sholl, D. S., Linßen, J., Stolten, D. & Weinand, J. M. Direct air capture enables sustainable methanol production in water-scarce regions. Nat. Commun. 17, 8495 (2026). https://doi.org/10.1038/s41467-026-76865-x

5. Liu, S., Xiao, Y. C., Kim, D., Guo, Z., Grignon, E., Li, Y., Munroe, I., Zhang, H., Zhu, J., Wu, Z., Edwards, J. P., Zhang, J., Liu, J., Papangelakis, P., Che, Y., Lee, H. S., Li, F., Sarma, P. V., Wang, Q., Wang, C., Scheidt, T., Miao, R. K., Seferos, D., Xu, Y. & Sinton, D. Redox-decoupled electrolysis for direct air capture of CO₂. Nat. Chem. Eng. 3, 261 to 271 (2026). https://doi.org/10.1038/s44286-026-00391-2

6. Tian, Z. & Liu, Y. Redox decoupling enables efficient electrochemical direct air capture. Nat. Chem. Eng. 3, 257 to 258 (2026). https://doi.org/10.1038/s44286-026-00384-1
