Wind and solar farms generate electricity with near-zero operational emissions, but their weather-dependent output can create gaps that may require emissions-intensive backup generation. Researchers are combining renewable-energy storage with carbon capture to tackle these challenges and create a more reliable, lower-carbon power system.
Image Credit: Aod Anon/Shutterstock.com
Renewable Energy Storage Challenge
Wind and solar power are inherently variable, making it difficult to match renewable generation with changing electricity demand. Solar generation follows the day-night cycle and is affected by cloud cover, while wind output can fluctuate from short-term changes to multi-day and seasonal variations.
Energy storage can help bridge these gaps by storing surplus renewable electricity and supplying it when generation falls. However, addressing prolonged shortages requires storage systems that can retain energy for days or even weeks.
Hydrogen offers one potential solution because surplus renewable electricity can power electrolyzers to split water into hydrogen and oxygen, storing energy in chemical form and later converting it back into electricity. It can also be stored for extended periods, including in large underground salt caverns, providing a potential route for medium- and long-duration energy storage. However, each repeated conversion step introduces energy losses, while hydrogen storage can require additional compression, infrastructure, or heat.
These challenges create an opportunity to integrate hydrogen storage with energy-intensive processes such as carbon capture, which requires substantial energy for CO2 separation and solvent regeneration. An integrated hydrogen storage and carbon capture system could exchange heat and energy between the two processes, reducing energy losses and improving overall efficiency.1,2,3
Click here to download a free PDF copy of this page
A Coupled Approach to Hydrogen Storage and Carbon Capture
Recently, a study published in Nature Communications designed a system that addresses the thermal penalty of solid-state hydrogen storage by coupling it with magnesium-based carbon capture.
The researchers combined hydrogen production, magnesium looping, MgH2 storage, and carbon capture so that heat released during hydrogen absorption could support CO2 capture rather than being lost.
The two processes operated across an overlapping temperature range of approximately 335 to 415 °C, allowing the system to exchange heat and materials.
During surplus wind generation, renewable electricity powers an electrolyzer to produce hydrogen, which is stored as MgH2. The resulting MgH2 releases heat during hydrogen absorption, which drives MgCO3 calcination into MgO and concentrated CO2. When renewable generation falls, MgO captures CO2 from industrial flue gas, releasing heat that decomposes MgH2 and releases hydrogen for electricity generation. Thus, the system recovers storage heat while combining carbon capture with thermochemical energy storage.
This thermal integration substantially improved MgH2 storage performance. Without heat recovery, the researchers reported a round-trip efficiency of around 4%, but coupling the storage process with magnesium looping increased this to approximately 19%, representing roughly a fivefold improvement.
The modeled system also achieved a carbon intensity of approximately −7.2 kg CO2 per MWh for offshore wind, although its performance depended on storage duration, wind availability, and system configuration.3
Alternate Routes to Integrated Energy and Carbon Management
Beyond coupling hydrogen storage with carbon capture, researchers are exploring other integrated systems that combine carbon management with energy generation, recovery, or storage.
Superstructure Optimization of CCUS with an Organic Rankine Cycle
One approach uses a superstructure model that integrates carbon capture, utilization and storage (CCUS) with renewable power and heat technologies. The system combines an energy-efficient CO2 removal unit with an organic Rankine cycle (ORC), parabolic trough collectors, photovoltaics, and battery storage to supply the substantial heating, cooling, compression, and electricity demands of CCUS.
The proposed system can remove up to 130,000 kg of CO2 per hour while producing up to 9.5 MW of electrical power, showing how waste heat recovery and renewable generation can integrate with carbon capture within a flexible energy hub.4
Low-Carbon Scheduling Model for Wind Power Fluctuations
Another study combined post-combustion carbon capture with wind power and energy storage to address both emissions and the intermittency of renewable generation. Its low-carbon scheduling model uses energy storage to manage fluctuations in electricity supply while carbon capture reduces emissions from thermal power generation.
At a carbon capture price of about $14 per ton of CO2, the modeled system deployed 127.6 MWh of energy storage with a power output of 74.9 MW and reduced unit electricity supply cost to about $0.021/kWh.5
Efficiency Comes with Complexity
Combining multiple functions within one system does not automatically improve its performance. The integration introduces its own engineering challenges.
Thermal management is a major concern because efficient heat exchange is needed between processes operating at different stages. For example, in the study, hydrogen storage and magnesium looping shared an operating range of approximately 335 to 415 °C, allowing heat from hydrogen absorption to support carbon capture. Without this integration, round-trip efficiency was only about 4%, compared with 19% with heat recovery.
Repeated hydrogen absorption and desorption of the magnesium-based storage material, along with repeated carbonation and calcination, also raises material durability concerns. These cycles could alter reaction kinetics, hydrogen and CO2 capacity, or structural stability over time, making extended durability testing necessary.
Scaling the concept would also increase system complexity and cost. Such systems may require multiple reactors, heat exchangers, gas-handling units, compression equipment, and energy-conversion technologies that must operate in coordination. This can increase control, maintenance, and operational requirements while raising capital costs.1,6
Future Outlooks
Combining renewable-energy storage with carbon capture reflects a broader shift toward integrated energy-system design. Rather than treating energy generation, storage, hydrogen, heat, and carbon management as separate processes, these systems can use their interactions to improve resource and energy utilization.
However, translating these concepts from laboratory and modeling studies to commercial-scale facilities will depend on efficiency, durability, cost, and maintaining a favorable carbon balance over the full life cycle. Addressing these challenges could enable renewable-energy storage and industrial carbon management to function as complementary components of shared energy infrastructure.
References and Further Reading
- Ward, K. R., Bamisile, O., Ejiyi, C. J., & Staffell, I. (2023). Time-averaged wind power data hides variability critical to renewables integration. Energy Strategy Reviews, 50, 101235. https://doi.org/10.1016/j.esr.2023.101235
- Cosgrove, P., Roulstone, T., & Zachary, S. (2023). Intermittency and periodicity in net-zero renewable energy systems with storage. Renewable Energy, 212, 299-307. https://doi.org/10.1016/j.renene.2023.04.135
- Harrison, A. R., Fulham, G. J., Hong, H., & Nie, B. (2026). Thermally coupled solid hydrogen storage and carbon capture for balancing intermittent renewable energy. Nature Communications, 17(1), 5514. https://doi.org/10.1038/s41467-026-72035-1
- Allahyarzadeh, A., & Sharifzadeh, M. (2025). Integrated carbon capture and renewable technologies for carbon neutral energy hubs: A network-ready superstructure model. Renewable Energy, 256, 124570. https://doi.org/10.1016/j.renene.2025.124570
- Meng, Q., He, Y., Hussain, S., Lu, J., & Guerrero, J. M. (2025). Low carbon optimization for wind integrated power systems with carbon capture and energy storage under carbon pricing. Scientific Reports, 15(1), 32714. https://doi.org/10.1038/s41598-025-17463-7
- Harrison, A. R., Fulham, G. J., Hong, H., & Nie, B. (2026). Thermally coupled solid hydrogen storage and carbon capture for balancing intermittent renewable energy. Nature Communications, 17(1), 5514. https://doi.org/10.1038/s41467-026-72035-1
