May 31 2010
Clean Energy USA offers the SunPower 210 solar panel. This solar panel incorporates 72 solar cells kept over an all black back sheet and delivers a conversion efficiency of 16.9%. The SunPower 210 Solar Panel delivers 50% more energy compared to conventional type of solar panels.
SunPower 210 Solar Panel
The front portion of this panel is covered with a tempered glass measuring 3.2 mm in thickness and enclosed in a strong anodized aluminum alloy 6063 type frame. This solar panel integrates an IP-65 rated junction box with three bypass diodes and uses 900 mm length output cable and multi-contact connectors. This solar panel module weighs 5 kg.
The SunPower 210 Solar Panel is designed to offer a Pmax of 210 W, a Vmpp of 40.0 V, an Impp of 5.25 A, a Voc of 47.7 V, an Isc of 5.75 A and a maximum system voltage of 600 V. The series fuse rating of this panel is 15 A, its peak power per unit area is 169 W/m², 15.7 W/ft² and the CEC PTC rating is 193.7 W. This solar panel offered by Clean Energy USA is designed to function in operating temperatures ranging from -40 to +85°C. This panel withstands a maximum load of 50 psf and hail storm of 23 m/s speed.
The SunPower 210 Solar Panel meets IEC and UL certificate requirements and certified for class C fire rating.
Source: http://ceusa.com
